Shantui SD32
Price excl. VAT
On Request
Print
INFO
Category
Crawler dozers
Brand / model
Shantui SD32
Year
2017
Condition
New/unused
Location
Jining,Shandong
Country
China
General grade
1
2
3
4
5
Mascus ID
4F058AF2
DETAILS
Full service history
Yes
Gross weight
82,012 lbs
Cabin type
Enclosed cab
Emission level
Stage II / Tier II
Engine
NTAA855-C360S10
Engine power
315 hp (232 kW)
Transmission
SHANTUI
Transport dimensions (LxWxH)
337008.06 x 162598.51 x 143307.16 inches
Original color
Yellow
Condition Info/Guarantee
yes
Production country
China
Delivery terms
FOB, CFR, CIF, EXW
Attachments
Ripper
Accessories
Air conditioning
Air conditioner
Documents
Additional information
ITEM UNIT SD32
L×W×H (Ripper not included) mm 6880×4130×3725
Operating weight (Ripper not included) t 37.2
Engine - CumminsNTA855-C360S10
Rated power kW/rpm 235/2000
Gradeability ° 30
Blade type - Straight tilt bladeSemi-U bladeAngle blade
Blade width mm Straight tilt blade 4130×1590Semi-U blade 4030×1720Angle blade 5000×1140
Dozing capacity m3 Straight tilt blade 10Semi-U blade 11.9Angle blade 6
Ma× drop below ground of blade mm 560
Lift height of blade mm 1560
Ripper type - Single ripperThree-shank ripper
Ripping depth of ripper mm Single ripper 1250Three-shank ripper 842
Lifting height of ripper mm Single ripper 955Three-shank ripper 883
Number of carriers (each side) - 2
Number of track rollers (each side) - 7
Number of track shoes (each side) - 41
Width of track shoe mm 560
Track gauge mm 2140
Ground length and ground pressure mm/MPa 3150-0.105
Pitch mm 228.6
Forward speed km/h 0–3.6
0–6.6
0–11.5
Reverse speed km/h 0–4.4
0–7.8
0–13.5
