Case CX 160 D for sale - the United States

Price Excluding Tax
USD164,500
Price Excluding Tax
USD164,500

BASIC INFORMATION

CategoryCrawler Excavators
Brand / modelCase CX 160 D
Year2019
Hours3,000 h
LocationGridley, California
Country
United States
Mascus ID3946BF4E

PRICING

Select Currency
Price Excluding Tax164,500 USD
TaxDoes not include reclaimable VAT
Price Including Tax-

DETAILS

Condition level grade (1-5)
EngineAR-4JJ1X
Engine power115 hp (84.58 kW)
Engine manufacturerIsuzu
Additional information2019 Case CX160D Excavator, Isuzu Engine AR-4JJ1X, Tier 4 Final, Water-Cooled, Turbocharged, 4-Cylinder, ISO Mirrors - 3, Viscous Cab Mounts, Upper Mounted Work Light, ROPS Protection, FOPS Cab Top Guard - Level 1, AC, Head, Defrost with Auto Climate Control, 3,000 hours.

Included Optional Equipment
-Long arm – 10 ft 0 in (3.05 m)
-Side-view camera

Engine
-Make: Isuzu
-Model: AR-4JJ1X
-Emissions Certification: Tier 4 Final
-Fuel Type: Requires ultra-low sulfur fuel B5 biodiesel tolerant
-Cooling: Water-Cooled
-Aspiration: Turbocharger with air cooled intercooler
-Cylinders: 4
-Displacement: 3L
-Fuel Injection: Direct injection - Electronic
-Net Horsepower - SAE J1349: 112 HP at 2200 RPM
-Gross Horsepower - SAE 1349: 115 HP at 2200 RPM
-Net Max Torque - SAE 1349: 257lbf ft

Drivetrain
-Travel Control: Dual stage relief counterbalance design
-Brakes: Mechanical disc
-Service Brakes: SAHR disc - each motor
-Two Travel Speeds: Max High Speed - 3.4 mph Max Low Speed - 1.7 mph (Automatic downshift)
-Drawbar Pull: 36,100 lbf
-Gradeability: 70% - 35 degree slope

Electrical
-Voltage: 24 Volts
-Alternator Rating: 50 amp
-Batteries: 2 x 12 Volt Battery reserve capacity - 72 Ah5 hour
-Work Lights - 4: 24 Volt/70 watt (1 boom, 1 upper, 2 cab)

Operator Environment
-Air Conditioner Output: 18,100 BTU an hr
-Heater Output: 20,150 BTU an hr
-Sound Level Inside Cab - ISO6395: 70 dBA
-Electrical Outlet: 12 Volt
-Cab Interior Light: 10 Watt
-Rear View Camera: Standard
-Seat: Heated, Air-suspension

Operating Weight
-Operating Weight: 38,400 lb
-With Shoes: 2 ft 0 in
-With Boom: 16 ft 11 in
-With Arm: 8 ft 7 in
-With Bucket: 1,067 lb
-With Counterweight: 6,980 lb
NOTE: With operator, full fuel, and standard equipment.

Ground Pressure
-Standard Operating Weight: 5.9 psi (0.41 bar) with 23.6 in (600 mm) triple grouser shoes

Hydraulics
-System Design: Open center
-Main pumps: Two-variable displacement axial piston
-Max. rated flow per pump: 37.5 gpm
-Max rated flow total: 75.02 gpm
-System pressures: Boom, arm and bucket 4,970 psi with Power Boost 5,260 psi Travel circuits 4,970 psi Swing circuits 4,050 psi
-Pilot pump: 1 x gear design
-Max. capacity: 5.8 gpm
-Controls: with boom arm holding valve
-Right track travel, bucket, boom and arm acceleration: 1 x Four-spool section
-Left track travel, auxiliary, swing, boom and arm acceleration: 1 x Five-spool section
-Work mode selections: SP - Speed Priority, H - Heavy Duty, A - Automatic
-Swing Motor: Fixed displacement axial piston
-Swing final drive: Planetary gear reduction
-Travel motor: Two-speed independent travel axial piston

Service Capacities
-Fuel tank: 79 gal
-Hydraulic system: 44 gal
-Hydraulic tank: 22 gal
-Engine oil with filter: 4.5 gal
-Swing drive: 1.3 gal
-Final drive: 1.5 gal
-Cooling system: 4.7 gal
-DEF tank: 22 gal

(NOTE: AVAILABLE ONLY VIA APPOINTMENT. PLEASE GET IN TOUCH AND SCHEDULE AN APPOINTMENT.)
