INFO

Category
Crawler Excavators
Brand / model
CAT 320 D
Year
2024
Hours
1,100 h
Country
China
General grade
1
2
3
4
5
Mascus ID
9D975A4D

PRICING

Select Currency

DETAILS

Customer asset number
1
Power type
Diesel
Serial number
1
Amount of previous owners
1
Date of latest inspection
2025-08-18
Undercarriage condition
good condition
Engine
Original
Gross weight
47,840 lbs
Engine power
176 hp (129 kW)
Engine manufacturer
Caterpillar
Registration number
1
Emission level
Stage V / Tier V
Bucket capacity
1.19 m3
Track width
23.6 inches
Top speed
5.70 km/h
Transport dimensions (LxWxH)
375.2 x 117.32 x 116.54 inches
Original color
Yellow
Dipper / stick length
114 inches
Condition Info/Guarantee
1 year
Production country
China
Delivery terms
FCA, FOB, CIF, EXW
Certificates
EPA, CE
Attachments
Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs.
Accessories
line rupture valve boom -> safety line rupture valve - boom/hoist
line rupture valve dipper -> safety line rupture valve - dipper/stick
Air conditioning
Engine pre-filter
Skeleton bucket
Rotating beacon
Extra equipment
Joystick control
Standard digging bucket
Additional information
卡特彼勒新一代CAT®320 液压挖掘机 参数配置 规格 动力燃油 厂商合资/进口 铲斗反铲 吨位(吨)20 整机工作重量(kg)21700 铲斗容量(m³)1.19 动臂长度(mm)5700 斗杆长度(mm)2900 性能 回转速度(rpm)11.25 回转扭矩(Nm)82k 行走速度(km/h)5.7 铲斗挖掘力(kN)150 斗杆挖掘力(kN)106 动力系统 发动机型号Cat® C4.4 额定功率(kw/rpm)129.4/2000 排量(L)4.40 气缸数(个)6 缸径×行程(mm)105×127 排放标准国Ⅳ 液压系统 主泵最大流量(l/min)429 工作液压油路(Mpa)35 行走液压回路(Mpa)34.3 回转液压回路(Mpa )27.5 油类容量 燃油箱(L)345 液压油箱(L)115 液压系统(L)234 发动机油更换量(L)15 冷却液(L )25 主体尺寸 运输总长度(mm)9530 运输总宽度(mm)2980 运输总高度(mm)2960 履带总长度(mm)4450 履带板宽度(mm)600 履带轨距(mm)2380 最小离地间隙(mm )470 配重离地间隙(mm)1050 后端回转半径(mm )2830 作业范围 最大挖掘半径(mm)9860 最大挖掘深度(mm)6720 最大挖掘高度(mm)9370 最大卸载高度(mm)6490 最大垂直挖掘深度(mm)5190
