CAT 320

We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours:24 hours, holidays and Sundays Contact: Lily Whatsapp: +86 17756597429 Mobile:+86 17756597429 Wechat:17756597429 Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs.

Caterpillar New Generation CAT®320 GC Hydraulic Excavator Parameter Configuration specification Power fuel Joint ventures/imports Bucket backhoe Tonnage (tons) 20 The working weight of the whole machine (kg) is 20600 Bucket capacity (m³) 1.0 Boom length (mm) 5700 Stick length (mm) 2900 performance Rotational speed (rpm) 11.3 Rotational torque (Nm) 74.4k Travel speed (km/h) 5.9 Bucket digging force (kN) 129 Stick digging force (kN) 99 dynamical system Engine model Cat® C4.4 Rated power (kw/rpm) 110 / 2000 Displacement (L) 4.4 Bore × stroke (mm) 105*127 Emission Standards Country IV. Hydraulic system The maximum flow rate of the main pump (l/min) is 429 Working hydraulic oil circuit (Mpa) 35 Traveling Hydraulic Circuit (Mpa) 34.3 Slewing hydraulic circuit (Mpa) 25 Oil capacity Fuel tank (L) 345 Hydraulic Tank (L) 115 Hydraulic System (L) 234 Engine oil change volume (L) 15 Coolant (L) 25 Body size Total length of transport (mm) 9530 Total width of transport (mm) 2980 Total height of transport (mm) 2960 Total track length (mm) 4250 Track shoe width (mm) 600/700 Track gauge (mm) 2380 Counterweight ground clearance (mm) 1050 Minimum ground clearance (mm) 470 Rear end turning radius (mm) 2830 Scope of work Maximum digging radius (mm) 9770 Maximum digging depth (mm) 6630 Maximum digging height (mm) 9440 Maximum unloading height (mm) 6580 Maximum vertical digging depth (mm) 6010
