CAT 324 D L
Price excl. VAT
Print
INFO
Category
Crawler Excavators
Brand / model
CAT 324 D L
Year
2021
Hours
766 h
Location
金山区, 上海
Country
China
General grade
1
2
3
4
5
Mascus ID
9EFB304A
PRICING
Select Currency
DETAILS
Power type
Diesel
Amount of previous owners
1
Full service history
Yes
Date of latest inspection
2025-07-10
Undercarriage condition
good
Engine
C7 ACERT
Gross weight
53,440 lbs
Engine power
190 hp (140 kW)
Bucket capacity
1 m3
Top speed
5.50 km/h
Original color
yellow
Condition Info/Guarantee
good
Production country
China
Delivery terms
FOB, CFR, CIF, EXW
Certificates
EPA, CE
Attachments
Hello, I'm Gavin, specializing in the sales of construction machinery. We have been working in this industry for decades and have four large machine storage yards in Shanghai. If you are interested in any machines, please feel free to contact me.
WhatsApp/WeChat: 0086 18019214942
Accessories
line rupture valve dipper -> safety line rupture valve - dipper/stick
Skeleton bucket
Diesel heater
Joystick control
Standard digging bucket
Cable bucket
V ditch bucket
Additional information
整机参数:
工作重量:24240kg
铲斗容量:约 1m³
动臂长度:5900mm
斗杆长度:2950mm
性能参数:
回转速度:9.6rpm
行走速度:3.5/5.5km/h
爬坡能力:70%(35°)
铲斗挖掘力:约 160kN(参考类似参数机型推测)
斗杆挖掘力:约 149kN(参考类似参数机型推测)
最大挖掘半径:10030mm
最大挖掘深度:6740mm
最大挖掘高度:9660mm
最大卸载高度:6700mm
发动机参数:
发动机型号:C7 ACERT
额定功率:140kW/2000rpm
排量:7.2L
气缸数:6
缸径 × 行程:102×130mm
冷却方式:水冷
液压系统参数:
主泵最大流量:235L/min
工作液压油路压力:35MPa
行走液压回路压力:35MPa
回转液压回路压力:24.5MPa
先导油路压力:3.9MPa
动臂油缸:2-135×1305mm
斗杆油缸:1-140×1660mm
铲斗油缸:1-120×1104mm
油类容量:
燃油箱:520L
液压油箱:145L
液压系统:300L(包括油箱)
发动机油更换量:30L
冷却液:30L
主体尺寸:
运输总长度:10060mm
运输总宽度:2990mm
运输总高度:3170mm
驾驶室全高:2980mm
配重离地间隙:1060mm
履带接地长度:3450mm
履带总长度:4250mm
履带板宽度:600mm
履带总宽度:2990mm
履带轨距:2380mm
最小离地间隙:470mm
后端回转半径:2940mm
