CAT 329 D

We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours,24 hours, holidays and Sundays Address: Shanghai City, China Contact: Nina Whatsapp: +86 18055199047 Mobile:+86 18055199047 Wechat:18055199047 Email: Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs

Model Number: 329D Machine Type: Crawler Excavator Power Source: Conventional Power Bucket Type: Backhoe Operating Weight Class: 29 tons Operating Weight: 29240 kg Overall Transport Length: 10410 mm Overall Transport Width: 2990 mm Overall Transport Height: 3180 mm Engine Parameters Engine Model: Cat® C7 ACERT™ Net Flywheel Power: 152 kW Net Power - ISO 9249: 152 kW Bore: 110 mm Stroke: 127 mm Displacement: 7.2 L Hydraulic System Parameters Maximum Flow (2x) - Main Implement System: 235 L/min Maximum Pressure - Implement: 35000 kPa Maximum Pressure - Travel: 35000 kPa Maximum Pressure - Swing: 27500 kPa Maximum Flow - Pilot System: 32.4 L/min Maximum Pressure - Pilot System: 3900 kPa Boom Cylinder - Bore: 140 mm Boom Cylinder - Stroke: 1407 mm Stick Cylinder - Bore: 150 mm Stick Cylinder - Stroke: 1646 mm CB1 Series Bucket Cylinder - Bore: 135 mm CB1 Series Bucket Cylinder - Stroke: 1156 mm Travel System Parameters Travel Speed: 3.5/5.3 km/h Maximum Drawbar Pull: 249 kN Track Shoe Width: 600 mm Track Gauge: 2390 mm Number of Track Shoes per Side - Standard Undercarriage: 45 Number of Track Shoes per Side - Extended Undercarriage: 50 Working Range Parameters Maximum Digging Radius at Ground Level: 10600 mm Maximum Digging Depth: 7170 mm Maximum Digging Height: 9990 mm Maximum Dumping Height: 7020 mm Maximum Vertical Digging Depth: 6510 mm Fluid Capacity Parameters Fuel Tank Capacity: 520 L Cooling System Capacity: 30 L Engine Oil Capacity: 30 L Swing Drive Capacity: 10 L Final Drive Capacity (per side): 6 L Hydraulic System (including tank): 310 L Hydraulic Tank Capacity: 145 L Other Parameters Swing Speed: 10.2 r/min Counterweight Ground Clearance: 1110 mm Rear Swing Radius: 3080 mm Minimum Ground Clearance: 490 mm
