INFO

Category
Crawler Excavators
Brand / model
CAT 336 D
Year
2025
Hours
780 h
Country
China
General grade
1
2
3
4
5
Mascus ID
BFDFB3B7

PRICING

Select Currency

DETAILS

Customer asset number
1
Power type
Diesel
Serial number
1
Amount of previous owners
1
Date of latest inspection
2025-08-19
Undercarriage condition
good condition
Engine
Original
Gross weight
81,351 lbs
Engine power
306 hp (225 kW)
Engine manufacturer
Caterpillar
Registration number
1
Emission level
Stage 5/Tier 4 Final
Bucket capacity
2.20 m3
Track width
23.6 inches
Top speed
4.70 km/h
Transport dimensions (LxWxH)
439.76 x 131.5 x 125.2 inches
Original color
Yellow
Dipper / stick length
126 inches
Condition Info/Guarantee
1 year
Production country
China
Delivery terms
FCA, FOB, CIF, EXW
Certificates
EPA, CE
Attachments
Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs.
Accessories
line rupture valve boom -> safety line rupture valve - boom/hoist
line rupture valve dipper -> safety line rupture valve - dipper/stick
Air conditioning
Engine pre-filter
Skeleton bucket
Rotating beacon
Extra equipment
Joystick control
Standard digging bucket
Additional information
卡特彼勒新一代CAT®336 液压挖掘机 参数配置 规格 动力燃油 厂商国产 铲斗反铲 吨位(吨)36 整机工作重量(kg)36900 铲斗容量(m³)2.2 动臂长度(mm)6500 斗杆长度(mm)3200 性能 回转速度(rpm)8.84 回转扭矩(Nm)143k 行走速度(km/h)4.7 铲斗挖掘力(kN)209 斗杆挖掘力(kN)166 最大牵引力(kN)302.5 动力系统 发动机型号C7.1 TTA 额定功率(kw/rpm)225/2000 排量(L)7.01 缸径×行程(mm)105*135 排放标准国Ⅳ 液压系统 主泵最大流量(l/min)560 工作液压油路(Mpa)35 行走液压回路(Mpa)35 回转液压回路(Mpa )29.4 油类容量 燃油箱(L)600 液压油箱(L)161 液压系统(L)373 发动机油更换量(L)25 冷却液(L )39 主体尺寸 运输总长度(mm)11170 运输总宽度(mm)3340 运输总高度(mm)3180 履带总长度(mm)5030 履带板宽度(mm)600 履带轨距(mm)2740 最小离地间隙(mm )510 配重离地间隙(mm)1260 后端回转半径(mm )3530 作业范围 最大挖掘半径(mm)11090 最大挖掘深度(mm)7550 最大挖掘高度(mm)10340 最大卸载高度(mm)7050 最大垂直挖掘深度(mm)5790

上海吉潘贸易有限公司

上海市松江区车墩镇莘莘路32号3799 201600 上海 上海 China
