Hitachi ZX 120
Price excl. VAT
7
Favorite
Share
Save searchPrint
INFO
Category
Crawler Excavators
Brand / model
Hitachi ZX 120
Year
2023
Hours
850 h
Country
China
General grade
1
2
3
4
5
Mascus ID
50D4B39C
PRICING
Select Currency
DETAILS
Customer asset number
1
Power type
Diesel
Serial number
1
Amount of previous owners
1
Date of latest inspection
2025-08-16
Undercarriage condition
good condition
Engine
Original
Gross weight
26,896 lbs
Engine power
89.7 hp (66 kW)
Engine manufacturer
Original
Registration number
1
Bucket capacity
0.52 m3
Track width
19.7 inches
Top speed
3.40 km/h
Transport dimensions (LxWxH)
299.61 x 98.03 x 107.87 inches
Original color
Orange
Dipper / stick length
99.2 inches
Condition Info/Guarantee
1 year
Production country
China
Delivery terms
FCA, FOB, CIF, EXW
Certificates
EPA, CE
Attachments
Packaging Details
1. Flat frame is more suitable for large construction equipment without disassembly.
2. Containers are the cheapest and fastest.
3. Bulk carriers are more suitable for large construction equipment.
4. Ro-ro shipment is fast and suitable for all kinds of machines.
You can choose any mode of transportation according to your needs.
Accessories
line rupture valve boom -> safety line rupture valve - boom/hoist
line rupture valve dipper -> safety line rupture valve - dipper/stick
Air conditioning
Engine pre-filter
Skeleton bucket
Rotating beacon
Extra equipment
Joystick control
Standard digging bucket
Additional information
日立ZX120挖掘机 参数配置
规格
整机工作重量(kg)12200
铲斗容量(m³)0.52
动臂长度(mm)4.6
斗杆长度(mm)2.52
原产地安徽合肥
吨位(吨)12
厂商合资/进口
动力传统动力
铲斗反铲
厂商合资/进口
动力传统动力
性能
回转速度(rpm)13.7
行走速度(km/h)3.4/5.5
爬坡能力(%)70/35°
接地比压(Kpa)37
铲斗挖掘力(kN)99
斗杆挖掘力(kN)65
动力系统
发动机型号五十铃ISUZU CC-4BG1TC
额定功率(kw/rpm)66/2150
排量(L)4.329
气缸数(个)4
冷却方式水冷
工作形式直喷
液压系统
主泵类型变量柱塞泵×2+齿轮泵×1
主溢流设定压力(Mpa)34.3
行走液压马达型式变量柱塞泵×2
回转液压马达型式定量柱塞泵×1
液压破碎管路是否标配否
油类容量
燃油箱(L)250
液压油箱(L)69(满箱130)
发动机油更换量(L)15.8
主体尺寸
运输总长度(mm)7610
运输总宽度(mm)2490
运输总高度(mm)2740
驾驶室全高(mm)2740
配重离地间隙(mm)890
履带接地长度(mm)2880
履带总长度(mm)3580
履带板宽度(mm)500
履带总宽度(mm)2490
履带轨距(mm)1990
最小离地间隙(mm )440
后端回转半径(mm )2130
作业范围
最大挖掘半径(mm)8270
最大挖掘深度(mm)5570
最大挖掘高度(mm)8570
最大卸载高度(mm)6160
最大垂直挖掘深度(mm)5020
推土铲举升或推深(mm)无推土铲
上海吉潘贸易有限公司
上海市松江区车墩镇莘莘路32号3799 201600 上海 上海 China
