Hitachi ZX 135

Price excl. VAT

Compnay LOGO
Images7
Hitachi ZX 135 Crawler Excavators
Hitachi ZX 135 Crawler Excavators
Hitachi ZX 135 Crawler Excavators
FavoriteFavorite
shareShare
Save searchSave search
Print

INFO

Category
Crawler Excavators
Brand / model
Hitachi ZX 135
Year
2023
Hours
800 h
Country
China
General grade
1
2
3
4
5
Mascus ID
C5B07837

PRICING

Select Currency

DETAILS

Customer asset number
1
Power type
Diesel
Serial number
1
Amount of previous owners
1
Date of latest inspection
2025-04-16
Undercarriage condition
Good Condition
Engine
Original
Gross weight
29,101 lbs
Engine power
89.7 hp (66 kW)
Engine manufacturer
Original
Registration number
1
Emission level
Stage V / Tier V
Bucket capacity
0.66 m3
Track width
98.0 inches
Transport dimensions (LxWxH)
287.01 x 98.03 x 107.87 inches
Original color
Original
Dipper / stick length
82.7 inches
Condition Info/Guarantee
1 Year
Production country
Japan
Delivery terms
FCA, FOB, CFR, CIF, EXW
Certificates
EPA, CE
Attachments
We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours,24 hours, holidays and Sundays Address: Shanghai City, China Contact: Jason Whatsapp: +86 13675656717 Mobile:+86 13675656717 Wechat:13675656717 Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs.
Accessories
Air conditioning
Additional hydraulics
Skeleton bucket
Battery disconnector
Show more
Additional information
规格 整机工作重量(kg)13200 铲斗容量(m³)0.19-0.66 动臂长度(mm)4.6（H型) 斗杆长度(mm)2.1/2.52/3.01 原产地日本 吨位(吨)13 厂商合资/进口 动力传统动力 铲斗反铲 厂商合资/进口 动力传统动力 性能 接地比压(Kpa)41 回转速度(rpm)13.7 行走速度(km/h)3.4/5.5 爬坡能力(%)70/35° 铲斗挖掘力(kN)99 斗杆挖掘力(kN)65 动力系统 发动机型号五十铃ISUZU CC-4BG1TC 额定功率(kw/rpm)66/2150 排量(L)4.329 气缸数(个)4 缸径×行程(mm)105×125 冷却方式水冷 工作形式直喷 液压系统 主泵类型变量柱塞泵×2+齿轮泵×1 主溢流设定压力(Mpa)34.3 行走液压马达型式变量柱塞泵×2 回转液压马达型式定量柱塞泵×1 工作液压油路(Mpa)34.3 行走液压回路(Mpa)34.3 回转液压回路(Mpa )32.3 先导油路(MPa)3.9 动臂油缸-个数×缸径×行程(mm)105×70 斗杆油缸-个数×缸径×行程(mm)115×80 铲斗油缸-个数×缸径×行程(mm)100×70 液压破碎管路是否标配否 油类容量 燃油箱(L)200 液压油箱(L)62( 发动机油更换量(L)15.8 冷却液(L )19 主体尺寸 运输总长度(mm)7290/7310 运输总宽度(mm)2490/2590/2690 运输总高度(mm)2740/2870 驾驶室全高(mm)2740/2870 配重离地间隙(mm)890 履带接地长度(mm)2880 履带总长度(mm)3580 履带板宽度(mm)500/600/700 履带总宽度(mm)2490/2590/2690 履带轨距(mm)1990 最小离地间隙(mm )440 后端回转半径(mm )2130 作业范围 最大挖掘半径(mm)7930/8300/8760 停机面最大挖掘半径(mm)7790/8160/8640 最大挖掘深度(mm)5120/5530/6020 最大挖掘高度(mm)8950/9220/9610 最大卸载高度(mm)6490/6760/7150 最大有效挖掘深度(mm)4880/5320/5840 推土铲举升或推深(mm)无推土铲Show more

上海吉潘贸易有限公司

上海市松江区车墩镇莘莘路32号3799 201600 上海 上海 China
