INFO

Category
Mini Excavators <7t (Mini Diggers)
Brand / model
CAT 307 E
Year
2019
Hours
3,988 h
Country
China
General grade
1
2
3
4
5
Mascus ID
B4D70556

PRICING

Select Currency

DETAILS

Power type
Diesel
Date of latest inspection
2025-05-08
Amount of previous owners
1
Undercarriage condition
98%
Gross weight
15,212 lbs
Emission level
Stage V / Tier V
Track width
19.7 inches
Bucket capacity
0.33 m3
Transport dimensions (LxWxH)
238.98 x 90.55 x 100 inches
Original color
original
Dipper / stick length
65.0 inches
Engine
original
Engine power
56.4 hp (41.5 kW)
Engine manufacturer
original
Condition Info/Guarantee
1 year
Production country
United States
Delivery terms
FCA, FOB, CFR, CIF, EXW
Certificates
EPA, CE
Attachments
We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours,24 hours, holidays and Sundays Address: Shanghai City, China Contact: Nina Whatsapp: +86 18055199047 Mobile:+86 18055199047 Wechat:18055199047 Email: Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs.
Accessories
Air conditioning
Skeleton bucket
Joystick control
Standard digging bucket
Show more
Additional information
整机参数 整机工作重量:6800kg 铲斗容量:0.31m³ 运输总长度:6070mm 运输总宽度:2300mm 运输总高度:2630mm 驾驶室全高:2630mm 配重离地间隙:775mm 履带总长度:2760mm 履带板宽度:450mm 前段工作装置最小回转半径:1690mm 后端回转半径:1820mm 性能参数 回转速度:10.8rpm 行走速度:5.1/3.2Km/h 爬坡能力:30 度 铲斗挖掘力:50.6kN 斗杆挖掘力:37.1kN 最大牵引力:56.9kN 发动机参数 发动机型号:卡特彼勒 C2.6 DI Turbo 额定功率:43Kw/rpm 排量:2.615L 缸径 × 行程:87×110mm 冷却方式:水冷 工作形式:直喷、涡轮增压、满足 EPA Tier2 标准 液压系统参数 工作液压油路:28Mpa 行走液压回路:28Mpa 回转液压回路:24Mpa 油类容量参数 燃油箱:125L 液压油箱:51L 液压系统:78L 发动机油更换量:11L 冷却液:14L 作业范围参数 最大挖掘半径:6300mm 停机面最大挖掘半径:6160mm 最大挖掘深度:4070mm 最大挖掘高度:7274mm 最大卸载高度:5190mm 推土板举升或推深:举升 445mmShow more

上海吉潘贸易有限公司

上海市松江区车墩镇莘莘路32号3799 201600 上海 上海 China
