Komatsu PC 35
Price excl. VAT
Print
INFO
Category
Mini Excavators <7t (Mini Diggers)
Brand / model
Komatsu PC 35
Year
2022
Hours
750 h
Country
China
General grade
1
2
3
4
5
Mascus ID
489CD512
PRICING
Select Currency
DETAILS
Power type
Diesel
Date of latest inspection
2025-09-23
Amount of previous owners
1
Undercarriage condition
Orginal
Gross weight
8,201 lbs
Emission level
Stage V / Tier V
Bucket capacity
0.18 m3
Original color
Orginal
Engine power
24.8 hp (18.2 kW)
Engine manufacturer
Orginal
Condition Info/Guarantee
1 Year
Production country
Japan
Delivery terms
FCA, FOB, CIF, EXW
Certificates
EPA, CE
Accessories
Joystick control
Standard digging bucket
Additional information
基本参数:
整机工作重量:3720-3870kg
额定功率:18.2kW(24.4hp)/2200rpm
铲斗容量:0.055-0.18m³
发动机型号:小松 3D88E-7
性能参数:
行走速度:高速 4.6km/h,低速 2.8km/h
回转速度:约 9rpm
铲斗挖掘力:约 29.9kN(不同型号可能有差异)
最大牵引拉力:3400kgf
爬坡能力:30°
尺寸参数:
全长:约 4780mm
全宽:1740mm
全高:2550mm
履带板宽度:300mm
尾部回转半径:约 1480mm
工作范围参数:
最大挖掘半径:约 5640mm
最大挖掘深度:约 3455mm
最大挖掘高度:约 5820mm(不同资料可能略有差异)
最大卸载高度:约 3480mm
液压系统参数:
主泵类型:变量柱塞泵 ×2
最大流量:32L/min
动臂压力:21.5MPa
斗杆压力:21.5MPa
铲斗压力:21.5MPa
回转压力:20.1MPa
燃油箱容量:41L
上海吉潘贸易有限公司
上海市松江区车墩镇莘莘路32号3799 201600 上海 Shanghai 上海 China
