Noblelift PT E15N
Price excl. VAT
On Request
Print
INFO
Category
Pedestrian stacker
Brand / model
Noblelift PT E15N
Year
2022
Hours
10 h
Country
Germany
General grade
1
2
3
4
5
Mascus ID
26431593
DETAILS
Power type
Electric
Customer asset number
5397
Maximum lift capacity
3,307 lbs
Load Center
23.6 inches
Maximum lift height
5.91 inches
Overall Lowered Height
49.6 inches
Lift mast
Other
Fork length
45.3 inches
Cabin
Closed cabin
Engine
Electric
Engine power
1 hp (0.74 kW)
Transport weight
271 lbs
Transport dimensions (LxWxH)
61.81 x 22.44 x 49.61 inches
Additional information
- Fahrgeschwindigkeit beladen / unbeladen km/h 4,2 / 4,4
- Hubgeschwindigkeit, beladen / unbeladen m/s 0,015 / 0,022
- Max. Steigfähigkeit beladen / unbeladen % 6 / 16
- Betriebsbremse: elektromagnetisch
- Antriebsmotor Leistung 60min kW 0,6
- Hubmotorleistung bei 10 % kW 0,50
- Batteriespannung, Nennkapazität V/Ah 24/20 ( 20/30 | 34/36 )
- Gewicht der Batterie kg 4,6
- Energieverbrauch nach VDI-Zyklus kWh/h
- Art der Antriebssteuerung: DC-Drehzahlregelung
- Schallpegel am Ohr des Fahrers nach EN 12053 dB(A) <70
- Reifen Polyurethan (PU)
- Reifengröße vorne (mm) ø 210x70
- Reifengröße hinten (mm) ø 80x93 (ø 80x70)
- Zusatzräder (Dimensionen) (mm) -/ø 80x3
